曲型輾片機
| Specification＼Type | Corrugated Fin Machine |
| Materials | Copper/Brass |
| Fin Height | 7mm ~12 mm (as your requirement) |
| Material thickness | Copper 0.035~0.05 mm Brass 0.04~0.05 mm |
| Rows | 2~7 Rows |
| Input speed | 70~100M/min (Adjustable) |
| Output speed | 12M~18M/min |
| Weight | 470Kgs |
| Cutting part | Electrical panel control |
| Air Requirements | 5 kgs/cm2 |
| Remark | We can design hemming 1mm for fin. |
